Question Details

A forced commutated thyristorized step - down chopper is shown in the figure. Neglect the ON - state drop across the power devices. Assume that the capacitor is initially charged to 50 V with the polarity shown in the figure. The load current (IL) can be assumed to be constant at 10 A. Initially, ThM is ON and ThA is OFF. The turn – off time available to ThM in microseconds, when ThA is triggered, is _______(rounded off to the nearest integer)

Show Answer
Correct Answer
50

Solution :

The correct answer is 50.

1. Circuit Parameters and Identification from the Diagram:
Based on the provided circuit diagram and the problem description:
- Input Source Voltage: V s = 50   V
- Commutating Capacitor: C = 10   μF (as labeled next to the capacitor in the image)
- Constant Load Current: I L = 10   A
- Initial Capacitor Voltage: V c = 50   V (with the top plate positive and bottom plate negative, indicated by the "+" and "-" signs on the capacitor in the image)

2. Circuit Operation and Commutation Process:
Initially, the main thyristor Th M is ON and conducting the load current. The auxiliary thyristor Th A is OFF.
When Th A is triggered to turn off the main thyristor:
- The auxiliary thyristor Th A turns ON, connecting the bottom plate of the capacitor to the positive terminal of the 50 V DC source.
- Since the capacitor is charged to 50 V (top plate positive), the potential at the cathode of Th M is raised to:
V cathode = V s + V c = 50 + 50 = 100   V
- Since the anode of Th M is connected to the 50 V supply, the voltage across the main thyristor becomes:
V Th M = 50 - 100 = - 50   V
This reverse voltage immediately turns Th M OFF.

3. Calculation of Turn-off Time available to Th M :
After Th M turns OFF, the constant load current I L flows through the capacitor and Th A , discharging the capacitor.
The main thyristor Th M remains reverse-biased until the capacitor voltage v c ( t ) drops to 0.
The available turn-off time (circuit turn-off time, t c ) is therefore the time required for the constant current I L to reduce the capacitor voltage from 50 V to 0 V:
t c = C · V c I L

Substituting the given parameters:
t c = 10 × 10 - 6   F × 50   V 10   A
t c = 50 × 10 - 6   seconds = 50   μs
